Sep 282015




Photo: Agência BrasíliaSorghum is already a drought-hardy crop, and is a critical food source across Africa’s harsh, semi-arid regions where water-intensive crops simply cannot survive. Now, as rainfall patterns become increasingly erratic and variable worldwide, scientists warn of the need to improve sorghum’s broad adaptability to drought.

Crop researchers across the world are now on the verge of doing just that. Through support from the CGIAR Generation Challenge Programme (GCP), advanced breeding methods are enhancing the capacity of African sorghum breeders to deliver more robust varieties that will help struggling farmers and feed millions of poor people across sub-Saharan Africa.

Photo: ICRISAT

A farmer in her sorghum field in Tanzania.

Sorghum at home in Africa

From Sudanese savannah to the Sahara’s desert fringes, sorghum thrives in a diverse range of environments. First domesticated in East Africa some 6000 years ago, it is well adapted to hot, dry climates and low soil fertility, although still depends on receiving some rainfall to grow and is very sensitive to flooding.

In developed countries such as Australia, sorghum is grown almost exclusively to make feed for cattle, pigs and poultry, but in many African countries millions of poor rural people directly depend on the crop in their day-to-day lives.

Photo: ICRISAT

A Malian woman and her child eating sorghum.

In countries like Mali sorghum is an important staple crop. It is eaten in many forms such as couscous or (a kind of thick porridge), it is used for making local beer, and its straw is a vital source of feed for livestock.

While the demand for, and total production of, sorghum has doubled in West Africa in the last 20 years, yields have generally remained low due to a number of causes, from drought and problematic soils, to pests and diseases.

“In Mali, for instance, the average grain yield for traditional varieties of sorghum has been less than one tonne per hectare,” says Eva Weltzein-Rattunde, Principal Scientist for Mali’s sorghum breeding programme at the International Crops Research Institute for the Semi-Arid-Tropics (ICRISAT).

In a continued quest to integrate ways to increase productivity, GCP launched its Sorghum Research Initiative (RI) in 2010. This aimed to investigate and apply the approaches by which genetics and molecular breeding could be used to improve sorghum yields through better adaptability, particularly in the drylands of West Africa where cropping areas are large and rainfall is becoming increasingly rare.

Kick starting the work was a GCP-funded collaboration between project Principal Investigator Niaba Témé, plant breeder at Mali’s Institut d’économie rurale (IER) and the RI’s Product Delivery Coordinator Jean-François Rami of the Centre de coopération internationale en recherche agronomique pour le développement (CIRAD; Agricultural Research for Development), France, with additional support from the Syngenta Foundation for Sustainable Agriculture in Switzerland.

The collaboration aimed to develop ways to improve sorghum’s productivity and adaptation in the Sudano-Sahelian zone, starting with Mali in West Africa, and expanding later across the continent to encompass Burkina Faso, Ethiopia, Kenya, Niger and Sudan.

Photo: F Noy/UN Photo

A farmer harvest sorghum in Sudan.

Sorghum gains from molecular research

Since 2008, with the help of CIRAD and Syngenta, Niaba and his team at IER have been learning how to use molecular markers to develop improved sorghum germplasm through identifying parental lines that are more tolerant and better adapted to the arid and volatile environments of Mali.

The two breeding methods used in the collaboration are known as marker-assisted recurrent selection (MARS) and backcross nested association mapping (BCNAM).

MARS

Photo: N Palmer/CIAT“MARS identifies regions of the genome that control important traits,” explains Jean-François. “It uses molecular markers to explore more combinations in the plant populations, and thus increases breeding efficiency.”

Syngenta, he explains, became involved through its long experience in implementing MARS in maize.

“Syngenta advised the team on how to conduct MARS and ways we could avoid critical pitfalls,” he says. “They gave us access to using the software they have developed for the analysis of data, and this enabled us to start the programme immediately.”

With the help of the IER team, two bi-parental populations from elite local varieties were developed, targeting two different environments found in sorghum cropping areas in Mali. “We were then able to use molecular markers through MARS to identify and monitor key regions of the genome in consecutive breeding generations,” says Jean-François.

“When we have identified the genome regions on which to focus, we cross the progenies and monitor the resulting new progenies,” he says. “The improved varieties subsequently go to plant breeders in Mali’s national research program, which will later release varieties to farmers.”

Jean-François is pleased with the success of the MARS project so far. “The development of MARS addressed a large range of breeding targets for sorghum in Mali, including adaptation to the environment and grain productivity, as well as grain quality, plant morphology and response to diseases,” he says. “It proved to be efficient in elucidating the complex relationships between the large number of traits that the breeder has to deal with, and translating this into target genetic ideotypes that can be constructed using molecular markers.”

Jean-François says several MARS breeding lines have already shown superior and stable performance in farm testing as compared to current elite lines, and these will be available to breeders in Mali in 2015 to develop new varieties.

Photo: ICRISAT

Eva Weltzein-Rattunde examines sorghum plants with farmers in Mali.

BCNAM

Like MARS, the BCNAM approach shows promise for being able to quickly gain improvements in sorghum yield and adaptability to drought, explains Niaba, who is Principal Investigator of the BCNAM project. BCNAM may be particularly effective, he says, in developing varieties that have the grain quality preferences of Malian farmers, as well as the drought tolerance that has until now been unavailable.

“BCNAM involves using an elite recurrent parent that is already adapted to local drought conditions, then crossing it with several different specific or donor parents to build up larger breeding populations,” he explains. “The benefit of this approach is it can lead to detecting elite varieties much faster.”

Eva and her team at ICRISAT have also been collaborating with researchers at IER and CIRAD on the BCNAM project. The approach, she says, has the potential to halve the time it takes to develop local sorghum varieties with improved yield and adaptability to poor soil fertility conditions.

“We don’t have these types of molecular-breeding resources available in Mali, so it’s really exciting to be a part of this project,” she says. “Overall, we feel the experience is enhancing our capacity here, and that we are closer to delivering more robust sorghum varieties which will help farmers and feed the ever-growing population in West Africa.”

Indeed, during field testing in Mali, BCNAM lines derived from the elite parent variety Grinkan have produced more than twice the yields of Grinkan itself. As they are rolled out in the form of new varieties, the team anticipates that they will have a huge positive impact on farmers’ livelihoods.

Photo: E Weltzein-Rattunde/ICRISAT

Malian sorghum farmers.

Mali and Queensland similar problem, different soil

In Mali and the wider Sahel region within West Africa, cropping conditions are ideal for sorghum. The climate is harsh, with daily temperatures on the dry, sun-scorched lower plains rarely falling below 30°C. With no major river system, the threat of drought is ever-present, and communities are entirely dependent on the 500 millimetres of rain that falls during the July and August wet season.

“All the planting and harvesting is done during the rainy season,” says Niaba. “We have lakes that are fed by the rain, but when these lakes start to dry up farmers rely mostly on the moisture remaining in the soil.”

Over 17 thousand kilometres to the east of Mali, in north-eastern Australia’s dryland cropping region, situated mainly in the state of Queensland, sorghum is the main summer crop, and is considered a good rotational crop as it performs well under heat and moisture stress. The environment here is similar to Mali’s, with extreme drought a big problem.

Average yields for sorghum in Queensland are double those in Mali—around two tonnes per hectare—yet growers still consider them low, directly limited by the crop’s predominantly water-stressed production environment in Australia.

One of the differentiating factors is soil. “Queensland has a much deeper and more fertile soil compared to Mali, where the soil is shallow, with no mulch or organic matter,” says Niaba. “Also, there is no management at the farm level in Mali, so when rain comes, if the soil cannot take it, we lose it.”

Photo: Bart Sedgwick/Flickr (Creative Commons)

Sorghum in Queensland, Australia.

Making sorghum stay green, longer

Another key reason for the difference in yields between Queensland and Mali is that growers in Queensland are sowing a sorghum variety of with a genetic trait that makes it more tolerant to drought.

This trait is called ‘stay-green’, and over the last two decades it has proven valuable in increasing sorghum yields, using less water, in north-eastern Australia and the southern United States.

Stay-green allows sorghum plants to stay alive and maintain green leaves for longer during post-flowering drought—that is, drought that occurs after the plant has flowered. This means the plants can keep growing and produce more grain in drier conditions.

“We’ve found that stay-green can improve yields by up to 30 percent in drought conditions with very little downside during a good year,” says Andrew Borrell from the Queensland Alliance for Agriculture and Food Innovation (QAAFI) at the University of Queensland (UQ) in Australia.

“Plant breeders have known about stay-green for some 30 years,” he says. “They’d walk their fields and see that the leaves of certain plants would remain green while others didn’t. They knew it was correlated with high yield under drought conditions, but didn’t know why.”

Stay-green’s potential in Mali

With their almost 20 years working on understanding how stay-green works, Andrew and his colleagues at UQ were invited by GCP in 2012 to take part in the IER/CIRAD collaborative project, to evaluate the potential for introducing stay-green into Mali’s local sorghum varieties and enriching Malian pre-breeding material for the trait.

A pivotal stage in this new alliance was a 12-month visit to Australia by Niaba and his IER colleague Sidi Coulibaly, to work with Andrew and his team to understand how stay-green drought resistance works in tall Malian sorghum varieties.

“African sorghum is very tall and sensitive to variation in day length,” explains Andrew. “We have been looking to investigate if the stay-green mechanism operates in tall African sorghums (around four metres tall) in the same way that it does in short Australian sorghum (one metre tall).”

Having just completed a series of experiments at the end of 2014, the UQ team consider their data as preliminary at this stage. “But it looks like we can get a correlation between stay-green and the size and yield of these Malian lines,” says Andrew. “We think it’s got great potential.”

Photo: S Sridharan/ICRISAT

Sorhum growing in Mozambique.

Sharing knowledge as well as germplasm

Eva Weltzein-Rattunde has played more of an on-the-ground capacity development role in Mali since accepting her position at ICRISAT in 1998. She says “the key challenges have been improving the infrastructure of the national research facilities [in Mali] to do the research as well as increasing the technical training for local agronomists and researchers.”

Photo: ICRISAT

A Malian farmer harvests Sorghum.

A large part of GCP’s focus is building just such capacity among developing country partners to carry out crop research and breeding independently in future, so they can continue developing new varieties with drought adaptation relevant to their own environmental conditions.

A key objective of the IER team’s Australian visit was to receive training in the methods for improving yields and drought resistance in sorghum breeding lines from both Australia and Mali.

“We learnt about association mapping, population genetics and diversity, molecular breeding, crop modelling using climate forecasts, and sorghum physiology, plus a lot more,” says Niaba. This training complemented previous training Niaba and IER researchers had from CIRAD and ICRISAT through the MARS and BCNAM projects.

“We [CIRAD] have a long collaboration in sorghum research in Mali and training young scientists has always been part of our mission,” says Jean-François. “We’ve hosted several IER students here in France and we are always interacting with our colleagues in Mali either over the phone or travelling to Mali to give technical workshops in molecular breeding.”

Photo: Rita Willaert/Flickr (Creative Commons)

Harvested sorghum in Sudan.

Working together to implement MARS in the sorghum breeding program in Mali represented many operational challenges, Jean-François explains. “The approach requires a very tight integration of different and complementary skills, including a strong conventional breeding capacity, accurate breeders’ knowledge, efficient genotyping technologies, and skills for efficient genetic analyses,” he says.

Because of this requirement, he adds, there are very few reported experiences of the successful implementation of MARS.  It is also the reason why these kinds of projects would normally not be undertaken in a developing country like Mali, but for the support of GCP and the dedicated mentorship of Jean-François.

sorghum quote 2“GCP provided the perfect environment to develop the MARS approach,” says Jean-François. “It brought together people with complementary skills, developed the Integrated Breeding Platform (IPB), and provided tools and services to support the programme.”

In addition to developing capacity, Jean-François says one of the great successes of both the MARS and the BCNAM projects was how they brought together Mali’s sorghum research groups working at IER and ICRISAT in a common effort to develop new genetic resources for sorghum breeding.

“This work has strengthened the IER and ICRISAT partnerships around a common resource. The large multiparent populations that have been developed are analysed collectively to decipher the genetic control of important traits for sorghum breeding in Mali,” says Jean-François. “This community development is another major achievement of the Sorghum Research Initiative.” The major challenge, he adds, will be whether this community can be kept together beyond GCP.

Considering the numerous ‘non-GCP’ activities that have already been initiated in Africa as a result of the partnerships forged through GCP research, Jean-François sees a clear indication that these connections will endure well beyond GCP’s time frame.

GCP’s sunset is Mali’s sunrise

Photo: S Sridharan/ICRISAT

Sorghum at sunset in Mozambique.

Among the new activities Jean-François lists are both regional and national projects aimed at building on what has already been achieved through GCP and linking national partners together. These include the West African Agricultural Productivity Program (WAAPP), the West Africa Platform being launched by CIRAD as a continuation of the MARS innovation, and another MARS project in Senegal and Niger through the Feed the Future Innovation Lab for Collaborative Research on Sorghum and Millet at Kansas State University.

“These are all activities which will help maintain the networks we’ve built,” Jean-François says. “I think it is very important that these networks of people with common objectives stick together.”

sorghum quoteFor Niaba, GCP provided the initial boost needed for these networks to emerge and thrive. “We had some contacts before, but we didn’t have the funds to really get into a collaboration. This has been made possible by GCP. Now we’re motivated and are making connections with other people on how we can continue working with the material we have developed.”

“I can’t talk enough of the positive stories from GCP,” he adds. “GCP initiated something, and the benefits for me and my country I cannot measure. Right now, GCP has reached its sunset; but for me it is a sunrise, because what we have been left with is so important.”

More links

Photo: ICRISAT

A sorghum farmer in her field in Tanzania.

Sep 242015


Hei Leung has always been passionate about diversity, especially genetic diversity, and that’s one reason why he leapt at the chance to get involved with the CGIAR Generation Challenge Programme (GCP) right from its inception more than a decade ago.

Photo: IRRIBut GCP’s attraction for Hei wasn’t just about genetic diversity; it was also about working with diverse institutes and researchers. At the time, Hei had been working for the International Rice Research Institute (IRRI) for some 10 years, on and off, including a stint at Washington State University in the USA.

“The whole idea of the Challenge Programme was to bring people together from different places instead of an individual CGIAR Centre doing things,” he says.

Hei also saw the likely spin-offs from rice research to other crops such as wheat, maize and sorghum, which are also crucial to food security.

Rice is a ‘model crop’ because of its small genome. This means researchers in major cereals like wheat and maize, which have much bigger genomes but share genes of similar functions, can benefit from our work with rice.”

Photo: Jeffreyw/Flickr (Creative Commons)

From little pizzas great programmes grow!

It all began in 2003, over pizza, in Rome. Hei remembers that his commitment to GCP started when he met with a small group of people including Robert Zeigler, who was to become the first Director of GCP, and who is currently Director General of IRRI.

“Little did we know that pizza was so inspiring,” Hei says, recalling that it was during that meeting that they agreed on the name: the Generation Challenge Programme.

GCP was formally launched in 2004 in Brisbane, Australia, at the 4th International Crop Science Congress.

Making the Programme ‘pro-poor’

Hei was initially involved with GCP as Subprogramme Leader for Comparative Genomics for Gene Discovery between 2004 and 2007, and later as a Principal Investigator for the Rice Research Initiative. Taking on his leadership role, Hei recognised from the start that many crops important to developing communities in Asia and Africa needed to become more drought-tolerant because of the increasing effects of climate change.

“We wanted to have a programme that is what we call ‘pro-poor’,” he says. “The majority of the world’s people depend on crops such as rice, wheat and maize for food.”

“I always feel that if you can solve eastern India’s problems, you can solve most of the problems in the world,” Hei adds. “If you travel in eastern India, you can see climate change happening day in, day out. You don’t have to wait 10 years or 50 years; it’s happening already. They either have too much or too little water. It’s a high-stress environment.”

Photo: N Palmer/CIAT


Women at work threshing rice near Sangrur, Punjab, India.

Rice is the world’s most widely consumed cereal crop, and is particularly important as the staple food of 2.4 billion people in Asia. GCP recognised rice’s importance and invested almost USD 29.5 million in rice research and development.

Furthermore, the genetic breeding lessons learnt from rice can also be applied to other staple crops such as wheat, maize and sorghum.

Other GCP-supported researchers used comparative genetics to determine if the same or similar genes – for example, the phosphorus starvation tolerance (PSTOL1) protein kinase gene found in rice – was also present and operating in the same manner in sorghum and maize.

They found sorghum and maize varieties that contained genes, similar to rice’s PSTOL1, that also conferred tolerance to phosphorus-deficient soils by enhancing the plant’s root system. They were then able to develop molecular markers to help breeders in Brazil and Africa to identify lines with these genes, which can now be used in breeding and developed as varieties for farmers growing crops, particularly in acidic soils.

Seeing the potential for novel researcher interactions

Hei also recognised that crops that received less scientific attention but remained important as regional staple foods, such as bananas and plantains (of the genus Musa), could benefit from comparative genomics research.

“We had a highly motivated group of researchers willing to devote their efforts to Musa,” remembers Hei, who is currently IRRI Program Leader of Genetic Diversity and Gene Discovery.

“GCP’s community could offer a framework for novel interactions among banana-related actors and players working on other crops, such as rice. So, living up to its name as a Challenge Programme, GCP decided to take the gamble on banana genomics and help it fly.”

Photo:  Asian Development Bank

A banana farmer at work in the Philippines.

However, after four years, Hei found it difficult to maintain his GCP leadership role as well as keep on top of his IRRI work: “They said I was 50 percent with IRRI and 50 percent with GCP, but it is never like that in reality. I was always doing two jobs, or at least one-and-a-half jobs, and I didn’t think I was doing a good enough job for either. I thought it was time for other people to come into GCP.”

While Hei stepped down from a leadership role, he remained active working on GCP projects throughout the life of the Programme.

Hei says that during the last five years of GCP, a lot of technology to characterise genetic diversity evolved “to bring high-quality science to accelerate our mission to help the poor areas of Asia and Africa.”

Streamlining GCP reporting: from three reports a year down to just one One of the things that initially bothered Hei during his GCP time was the reporting requirements: “I remember we used to ask people to submit a mid-year report, end-of-year report and an update. “So I stuck my neck out during the last couple of years, and I said: ‘Guys, stop it. Don’t ask for these reports. They become mechanical. People just fill in the blanks. Ask for just one report before or after our annual meeting: just one report that people are excited to write about. And that was adopted.”

A MAGIC affair

The development of MAGIC (multi-parent advanced generation intercross) populations is the project that Hei gets most excited about. From these populations, created by crossing different combinations of multiple parents, plant lines can be selected that have useful characteristics such as drought tolerance, salinity tolerance and the ability to produce better quality grain.

“Now many crop breeders are calling for MAGIC populations,” says Hei. “I feel proud that at GCP we decided to support this concept and activity. This is one of GCP’s most important legacies and it’s one of my most favourite things.”

Photo: IRRI

Hei Leung looking relaxed in the lab at IRRI.

Honoured as a Fellow of the American Phytopathological Society (APS), Hei is recognised “for his leadership in the international community toward building and distributing rice genetic and genomic resources and creating capacity in plant pathology in the developing countries of Asia.”

Hei’s GCP leadership and research have clearly provided him with an important platform for taking on leadership and champion roles linking many individuals and organisations across Asia and Africa. His ASP profile concludes: “His promotion of collaborative research and his leadership in such programmes in the developing world have contributed to the building of a dynamic research community that promotes both basic knowledge and food security for Asia and the world.”

Making a difference to food security and farmer’s lives in developing countries is what GCP is all about. Such differences have been made possible through collaborative links that connect a diversity of organisations and people with the latest research in genetic diversity and breeding techniques.

Photo: IRRI

A farmer transplants rice in the Philippines.

It’s amore!

hei quoteHei recalls his personal and professional journey with GCP with much affection: “I think that it has been a wonderful scientific journey in terms of knowing the science and opening up my mind to being more receptive to alternative ways of doing things.

“There have been so many friends I have met through networking with GCP. Sometimes you go through bumpy roads, but anything you do will have bumpy times. And it’s very unusual to have a programme so illuminating. We honoured our commitment to finish in 10 years. It is a programme that had a fresh start and a clean ending.

“Most importantly, GCP has enabled plant breeders to embrace cutting-edge science through partnerships that focused on improving crop yields in areas previously deemed unproductive,” he says. “GCP is unique, one-of-a-kind, and I love it!”
